Waveform Output Channel |
Frequency Range |
0.1Hz(DC)~5MHz |
Resolution |
0.01Hz |
DAC Clock |
0~50MHz Continuously adjustable, in step of 0.2Hz |
Channels |
1CH waveform output |
Memory Depth |
256KSa |
Vertical Resolution |
14 Bits |
Stability |
<30ppm td=""> |
Amplitude |
±10V Max. |
Output Impedance |
50 Ω |
Output Current |
50mA Vpeak=100mA |
Low Pass Filter |
5MHz, 1MHz, 100KHz, 10KHz, 1KHz Programmable Control |
Harmonic Wave distortion |
-65dBc(1KHz), -53dBc(10KHz) |
Frequency Counter Channel 1 |
Range |
DC~25MHz |
Input Power |
400mVpp~25Vpp |
Coupling Mode |
AC, DC Programmable |
Accuracy |
±Time Base Error ±1 Count |
Input Impedance |
50KΩ |
Frequency Counter Channel 2 |
Range |
25MHz~2.7GHz |
Input Power |
400mVpp~25Vpp |
Coupling Mode |
AC |
Accuracy |
±Time Base Error ±1 Count |
Input Impedance |
50 Ω |
Digital Input and Output |
Bits |
8 Bits+ Synchronized Signal 1 Bit + External Signal 1 Bit |
Level |
3/5V TTL/CMOS |
Working Environme nt |
Working Temperature |
0~70 Centigrade |
Working Humidity |
0~65% |
Weight |
0.7Kg |
