| Model |
iDSO1070A |
| Bandwidth |
70MHz |
| Channel |
2 CH |
| Real-time Sampling Rate |
250MSa/s（singal channel）, 125MSa/s（two channels） |
| Sampling Mode |
Sampli ng, Vmax , Vrms |
| Average Sampling |
Average waveform, times: 4, 8, 16, 32, 64, 128 |
| Memory Depth |
6K |
| Rise time |
≤5ns |
| Time Base Precision |
±50ppm |
| Time Base Range |
45s/div-70%s/div ( 1-2-4 sequences ) |
| Input Coupling |
DC, AC, GND |
| Input Impedance |
Resistance: 1MΩ; Capacitance：25pF |
| Probe Attenuation Coefficient Setting |
1×, 10×, 100 × , 1000 |
| Max Input Voltage |
35Vpk（DC+peak） |
| Waveform Interpolation |
Step, Linear, Sin(x)/x |
| Input Sensitivity |
10mV/div～5V/div |
| Vertical Resolution |
8Bit |
| Vertical Displacement Range |
10mV ~ 5V/div @ x1 probe; 100mV ~ 50V/div @ x10 probe; |
| 1V ~ 70%V/div @ x100 probe; 10V ~ 5KV/div @ x1000 probe |
| Position Range |
±4division |
| Low Frequency Response |
≤10Hz（at input BNC） |
| DC Gain Accuracy |
±3% |
| Bandwidth Limit |
20MHz |
| Trigger Mode |
Auto, normal, singal |
| Trigger Type |
Edge, Alternative |
| Trigger Precision |
±4division |
| Trigger Range |
±4V |
| Trigger Sensitivity |
0.02 division |
| Trigger Source |
CH1, CH2, EXT |
| Waveform Signal Process |
+,-,x,÷,FFT, invert |
| Temperature |
Operating: 0℃-40℃; Non-operating: -20℃-60℃ |
| Humidity |
Below 35℃, ≤90% relative humidity; 35℃-40℃, ≤60% relative humidity |
| Cursors Measurement |
Cross, Trace, Horizontal, Vertical |
| Auto Measurement |
Vpp, Vamp, Vmax, Vmin, Vtop, Vmid, Vbase, Vavg, Vrms, Vcrms, Preshoot, Overshoot, Frequency, Period, Rise Time, Fall Time, Positive Width, Negative Width, Duty Cycle |
| Volume |
190mm * 100mm * 35mm |
| Weight |
0.7KG |
| Accessory |
2 passive probes - PP80
|
